Shotcrete is a placement method for concrete. So, standard concrete tests for shrinkage are applicable. You will find an article from Shotcrete magazine, “Shotcrete Testing—Who, Why, When, and How,” helpful. Here’s a link to the archived PDF of the article (shotcrete.org/wp-content/uploads/2020/01/2011Sum_Hanskat.pdf). The specific section on drying shrinkage tests says:
“Drying shrinkage of the shotcrete can be tested using general provisions of ASTM C157. Because the shotcrete is shot into a large panel and not into the relatively small mold specified by ASTM for the shrinkage test beam, it is recommended that a beam approximately 11.25 in. (285 mm) in length be sawed from a test panel. As most shotcrete uses coarse aggregate less than 1 in. (25 mm), a 3 in. (75 mm) thick panel with a 3 in. (75 mm) wide cut should approximate the ASTM requirements. The A/E should specify in the contract documents drying shrinkage limits that are appropriate for the design of the structure.”
Since shotcrete is simply a placement method for concrete, the R-value is the same as cast concrete. ACI 122R-14, “Guide to Thermal Properties of Concrete and Masonry Systems,” would be a good reference.
Each manufacturer of concrete constituents needs to have their products tested by NSF if they want NSF 61 certification. Whether the fibers need NSF 61 certification is an issue with the local authority having jurisdiction for exposure of components to potable water supply systems in your state. Generally, this is the state EPA-type agency, but maybe a federal agency if on a federal project.
We don’t maintain a database of manufacturer products that meet NSF 61. However, you can readily identify contacts for the fiber manufacturers who are ASA corporate members with our Buyers Guide at https://shotcrete.org/products-services-information/buyers-guide/. When entering the Buyers Guide, you can select “Fiber + Reinforcement Sales” and the fiber type subcategory to get a list of our member fiber suppliers.
Membership supports the mission of ASA to provide knowledge, resources, qualification, certification, education, and leadership to increase the acceptance, quality, and safe practices of the shotcrete process.
Annual Dues (Sustaining Corporate Membership includes three Corporate Additional Individual memberships and special recognition in ASA’s Buyers Guide and on the ASA website)
$1500
$1200
$100
$375
$65
Free
Free
Company and specialty information listed in ASA’s online Buyers Guide
X
X
Discount on ACI Shotcrete Nozzleman Certification and Education
X
X
Opportunity to be featured as either a Sustaining Corporate or Corporate Member Profile, respectively, in Shotcrete magazine
X
X
Exclusive opportunity to submit items for the Industry News and New Products & Processes columns in Shotcrete magazine
X
X
X
X
Discounted ASA member prices on all ASA products
X
X
X
X
X
X
X
Contacts to receive bid requests from our Online Project Bid Request Tool
4
1
1
Subscription to quarterly Shotcrete magazine (hard and electronic copy)
X
X
X
X
X*
X
X*
Permission to include ASA logo on corporate letterhead and business cards
X
X
X
X
Permission to display ASA logo on company website
X
X
Discounted pricing on advertising in Shotcrete magazine
X
X
X
X
X
Complimentary inclusion of advertising company logo from the ASA website to your company website during your advertising quarter
X
X
Voting privileges at committee meetings and director/officer elections
4
1
1
1
Fulfills membership requirement for ASA’s annual Outstanding Shotcrete Project Awards Program
X
X
Complimentary annual Onsite Learning Seminars**
2
1
1
Corporate Additional Individual memberships are available for company employees ($200 savings per employee)
X
X
Access to ASA’s “Safety Guidelines for Shotcrete” via ASA’s member Communities portal through “My ASA” at www.shotcrete.org
1
1
Complimentary ASA shotcrete brochure each year
25
25
5
5
5
Complimentary ASA reflective hardhat sticker each year
10
10
1
1
1
*Members outside North America will only receive electronic copies. **Further education for in house, specifiers, or government agencies (1-2 hours)
Any redistribution or reproduction of part of all of the contents in any form is prohibited other than the following:
You may print or download extracts for your personal and non-commercial use only.
You may copy the content to individual third parties for their personal use, but only if you acknowledge the website as the source of the material.
You may not, except with the ASA’s express written permission, distribute or commercially exploit the content. Nor may you transmit it or store it in any other website or other form of electronic retrieval system.
About ASA Committees
Committee meetings are open to the public and ASA welcomes and encourages the participation of all interested parties in the shotcrete industry.
Board of Directors
The Board of Directors shall have supervision, control, and direction of the affairs of the Association, shall determine its policies within the limits of the ASA bylaws, shall actively pursue its purpose and shall oversee the disbursement of its funds.
Mission Statement: To oversee the technical activities of ASA, including the review and evaluation of technical presentations, publications, handouts, etc., and the appraisal of research projects under consideration for ASA sponsorship.
ACI 506.2-13, “Specification for Shotcrete,” is an excellent resource for answering your questions. ACI 506.2 addresses both preconstruction panels and test panels used for material quality control during construction. ACI 506.2, Section 1.5.1.4, requires that when preconstruction panels are required, the Contractor shall “Construct test panels for each proposed shotcrete mixture, each anticipated orientation, and each proposed nozzleman.” Preconstruction test panels vary in size to adequately represent the embedded reinforcement and section thicknesses in the work to be done.
Test panels shot during construction for evaluation of material properties are covered in ACI 506.2, Section 1.6.3.1, which states: “Construct a test panel for each mixture, each nozzleman, and each work day or for every 50 yd3 (38 m3) placed—whichever results in the most panels. The face dimensions of a test panel shall be a minimum of 16 x 16 in. (406 x 406 mm) with a minimum depth of 5 in. (127 mm). For toughness testing in accordance with ASTM C1550, the face dimension shall be 30.5 in. (775 mm) in diameter and 3 in. (76 mm) thick. Shoot test panels in a vertical orientation only unless otherwise specified.”
ACI 506.2-13 has extensive provisions for the submittals, testing, materials, and execution of shotcrete work by a shotcrete contractor. It cites many of the ASTM testing standards appropriate for shotcrete construction. We recommend you review the document in its entirety to become familiar with current industry standards.
ACI 506.1R-08, “Guide to Fiber-Reinforced Shotcrete,” is a good reference for general use of fibers in shotcrete. If looking at underground applications for shotcrete, ACI 506.5R-09, “Guide to Specifying Underground Shotcrete,” will also offer guidance. The ACI 506 documents are available in hard copy format on our bookstore website with ASA member discounts (shotcrete.org).
Because shotcrete is a method for placing concrete, many, if not most, of the properties of fiber-reinforced concrete, as found in ACI 544 committee documents, are applicable to shotcrete.
Shotcrete is concrete placed at high velocity to achieve compaction. It is dependent on the projection of material with air velocity of 60 to 80 mph (97 to 129 km/h) from the nozzle to consolidate the concrete material in place. It cannot be hand-applied. You may consider hand-applied pre-packaged mortar mixtures to achieve your results, although strength and durability may be less than a similar section with shotcrete because the hand-applied material is not fully compacted. Another alternative is to create an inner cylinder and cast concrete in the space between the box and the form. The concrete could then be vibrated for consolidation.
Recent research into velocity of the material stream shot from the nozzle is approximately 60 to 80 mph (97 to 129 km/h) in the middle of the stream. Outer portions of the stream are slowed and show speeds of about 45 mph (72 km/h). Here’s a link to the Technical Tip published in the Fall 2013 Shotcrete magazine that provides more complete documentation of the research: shotcrete.org/wp-content/uploads/2020/01/2013Fal_TechnicalTip.pd.
